I/O modules PCD1|PCD2
Analogue I/O modules
5
5.15 Analogue thermocouple modules
PCD2.W745 4-channel thermocouple modules for J, K … thermoelemets
Supported temperature sensors are:
● Thermocouples–TCtypeJ,K
● Resistivetemperaturedetectors–RTD’s type Pt 100, Pt 1000, Ni 100, Ni 1000
I/O modules and I/O terminal blocks may only be plugged in and removed when
the Saia PCD
®
and the external +24 V are disconnected from the power supply.
The module PCD2.W745 is described in the manual 26-796.
