I/O modules PCD3
Analogue output modules, electrically isolated from the I/O Bus
6
6.11 Analogue output modules, electrically isolated from the I/O Bus
PCD3.W605 6 electrically isolated analogue outputs 10 bit, 0…10 V
PCD3.W615 4 electrically isolated analogue outputs 10 bit, 0…20 mA
PCD3.W625 6 electrically isolated analogue outputs 10 bit, –10 V…+10 V
Galvanic separation of outputs to Saia PCD
®
, channels themselves not separated
I/O modules and I/O terminal blocks may only be plugged in and removed when the Saia
PCD
®
and the external +24?V are disconnected from the power supply.
