SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-129
I/O modules PCD1|PCD2
PCD2.H32x
5
5.19.2 PCD2.H32x, motion control modules for servo-drives
There are four module types available:
PCD2.H320: 2 axes with 24 V encoder
PCD2.H325: 2 axes with 5 V and SSI absolute value encoder
PCD2.H322: 1 axis (slave operation) with 24 V encoder
PCD2.H327: 1 axis (slave operation) with 5 V and SSI absolute value encoder
The PCD2.H32x motion control modules are intelligent I/O modules in the PCD2
series. They are used to position two independent axes, with one variable speed
AC or DC drive (servo-motor) each, or two axes as an electronic transmission.
This requires the drive unit to have a power stage and incremental shaft encoder
for capturing position or speed. Displacement control may also be achieved with
an SSI absolute value encoder.
Each module contains a DSP processor that independently controls every
movement according to parameters supplied by the user program: velocity,
acceleration and destination position (“PID control”). This enables each axis
to execute independent movements, perform S-curve and trapezoidal motion
proles,changevelocityandacceleration,performinterruptfunctionsandrecord
the current axis position during motion.
In a PCD2 with expansion housing, up to 7 PCD2.H32x modules can be operated
in parallel.
Technical data
Function-specic data
Number of systems: 2 for H320/5
1 for H322/7 + 1 H100 counter input 4 DI + 1 DO
Motion parameters
31-bit registers are used for destination position, velocity and acceleration, numerical
range ± 2
30
)
Position Units and resolution selectable (depending on mechanical
factor)
Velocity Units and resolution selectable (depending on mechanical
factor)
Acceleration Units and resolution selectable (depending on mechanical
factor)
PID controller Sample time 100 µs / axis, programmable proportional,
integralanddi󰀨erentialfactors.Sampletimefordi󰀨erential
part can be programmed separately. Additional velocity and
acceleration feed-forward (all 16 bit values)
Analogue controller
output
Velocity set point ± 10 V
(resolution 12 bit)
Counting frequency max. 125 kHz for H320/5
max. 250 kHz for H322/7
