SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
9-11
PCD2.G200
Example of linearization
9
9.4 Example of linearization
NTCsensorsarenotinplementedintheDeviceConguratorbecausethesesen-
sors are not standardized. To use a NTC with the module PCD2.G200, please
congurethedesiredchannelinmode“0…300kΩ”andusethelinearizationFBox
available in PG5 environment.
In the FBox the resistance values of the sensor have to be entered that the con-
version to a temperature is executed.
A project example can be downloaded from the SBC Support Website:
http://www.sbc-support.com/en/services/getting-started/programm-
examples/pg5-21/general.html
