Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-7
I/O modules PCD1|PCD2
Overview
5
5.1.2 Power consumption of PCD2 input/output modules
Type
PCD2.…
Maximal
internal current
consumption
I from +5 V [mA]
Maximal
internal current
consumption
I from +V [mA]
Maximal external current
consumption
at 24 V, I [mA]
E11x
E16x
E500
E61x
24
72
1
24
---
---
---
---
8 inputs, 6 mA/input
16 inputs, 4 mA/input
6inputs,10 … 12mA/input
8 inputs, 5 mA/input
A200
A220
A251
A300
A400
A410
A46x
B100
B160
G200
15
20
25
20
25
24
74
25
120
12
---
---
---
---
---
---
---
---
---
35
32 mA
1)
48 mA
1)
64 mA
1)
Load current
Load current
Load current
Load current
Load current
Load current
Load current
W200/210
W220
W300/310
W3x5
W340/360
W350
W380
W4x0
W5x0
W525
W600
W605/625
W610
W615
W720
W745
8
8
8
60
8
8
25
1
200
40
4
110
110
55
60
200
5
16
5
0
20
30
25
30
---
---
20
---
---
---
100
---
---
---
---
---
---
---
---
W410 100 mA
2)
---
Load current
---
---
100 mA
2)
90 mA
---
---
H100/H110
H150
H210
H310/H311
H320/H322
H325/H327
90
25
85
140
230
250
---
---
---
---
20
20
CCO output: load current
Load current
Load current
max. 15 mA
Load current
Load current
1) Coil resistance of the relay 3 kOhm
2) Basic consumption 20 mA, plus 0..20 mA per output
