Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-8
I/O modules PCD1|PCD2
Overview
5
5.1.3 Maximal current consumption from base units
Base unit internal 5 V-
Bus
internal +V-
Bus
PCD1 750 mA 100 mA
PCD2.M110/M120 (before hardware version H) 1100 mA 200 mA
PCD2.M110/M120 1600 mA 200 mA
PCD2.M150/M170 1600 mA 200 mA
PCD2.C200 1500 mA 630 mA
PCD2.M2210-C15 500 mA 200 mA
PCD2.M480 2000 mA 200 mA
PCD2.M4x60 800 mA 250 mA
PCD2.M5xx0 1400 mA 800 mA
PCD2.C1000 1400 mA 800 mA
PCD2.C2000 1400 mA 800 mA
