5.12 Analogue input and output modules
PCD2.W500 2 analogue inputs 12 bit + 2 analogue outputs 12 bit,
0 … 10 V, –10 V … +10 V *)
PCD2.W510 2 analogue inputs 12 bit + 2 analogue outputs 12 bit,
0 … +20 mA, -20 … +20 mA *)
*)jumperselectable
I/O modules and I/O terminal blocks may only be plugged in and removed when
the Saia PCD
®
and the external +24 V are disconnected from the power supply.
