5.9 Analogue input modules with electricaly isolation
PCD2.W305 7 analogue inputs 12 bit resolution, 0 … 10 V
PCD2.W315 7 analogue inputs 12 bit resolution, 0 … 20 mA
PCD2.W325 7 analogue inputs 12 bit resolution, –10 V … +10 V
Galvanic separation of outputs to Saia PCD
®
, channels themselves not sepa-
rated
I/O modules and I/O terminal blocks may only be plugged in and removed when
the Saia PCD
®
and the external +24 V are disconnected from the power supply.
