I/O modules PCD3
PCD3.W4x0
6
6.10.1 PCD3.W4x0, analogue outputs, 4 channels, 8 bit resolution
Application
High-speedoutputmodulewith4outputchannelsof8bitseach.Di󰀨erentoutput
signals can be chosen with the aid of jumpers. Suitable for processes in which a
large number of actuators have to be controlled, such as in the chemical industry
and building automation.
Module overview
PCD3.W400: Single signal module with 4 output channels of 8 bits
each 0…10 V
PCD3.W410: General purpose module with 4 output channels of 8 bits each.
Signals can be selected from 0…10 V, 0…20 mA or 4…20 mA.
Technical data
Number of output channels: 4, short circuit protected
Signal ranges: W400 0…10 V
W410 0…10V*) selectable
0…20 mA with
4…20 mA
}
jumpers
Resolution (digital representation): 8 bits (0…0.255)
Conversion time D/A: < 5 µs
Load impedance: for 0…10 V: ≥3kΩ
for0…20mA: 0…500Ω
for4…20mA: 0…500Ω
Accuracy (of output value): for 0…10 V: 1% ± 50 mV
for 0…20 mA: 1% ± 0.2 mA
for 4…20 mA: 1% ± 0.2 mA
Residual ripple: for 0…10 V: < 15 mV pp
for 0…20 mA: < 50 µA pp
for 4…20 mA: < 50 µA pp
Temperature error: typ. 0.2% (across temperature range 0…+55 °C)
Burst protection:
(IEC 801-4)
± 1 kV, with unshielded cables
± 2 kV, with shielded cables
Internal current consumption:
(from +5 V bus)
1 mA
Internal current consumption:
(from V+ bus)
30 mA
External current consumption: max. 0.1 A (type PCD3.W410 only, for current outputs)
Terminals:
Plug-in 10-pole spring terminal block (4 405 4954 0) or
pluggable 10-pole screw terminal block (4 405 4955 0),
both for wires up to 2.5 mm²
*)Factorysetting
