I/O modules PCD3
PCD3.W6x5
6
6.11.1 PCD3.W6x5, analogue outputs electrically isolated from the I/O Bus,
6(4) channels, 10 Bit resolution
Application
High-speed output module for general use, electrically isolated, 6 (4) channels,
eachwith10bitresolution.Di󰀨erentvariantsforvoltage0…10V,–10V…+10V
and current 0…20 mA are available.
Module overview
Channels Resolution
PCD3.W605: Voltage 0…10 V 6 (A0…A5) 10 mV
PCD3.W615: Current 0….20 mA 4 (A0…A3) 20 µA
PCD3.W625: Voltage –10…+10 V 6 (A0…A5) 20 mV
Technical data
Output ranges: see module overview
Galvanic separation: 500 V, electrical isolation of outputs to Saia PCD
®
,
channels themselves not separated
Resolution (digital representation): 10 bits (0…1023)
Load resistance: W605:  >3kΩ
W615:  <500Ω*
W625:  >3kΩ
Accuracy at 25°C W605: ± 0.4%
W615: ± 0.7%
W625: ± 0.4%
Temperature error (0…+55°C) ± 0.25%, 100 ppm/K or 0.01%/K
Short circuit protection: yes (permanent)
EMC protection: acc. to standards:
- ENV 50 141
- EN 55 022
- EN 61000-4-2
- EN 61000-4-4
- EN 61000-4-5
Timeconstantofoutputlter: W605: typ. 1 ms
W615: typ. 0.3 ms
W615: typ. 1 ms
Internal current consumption:
(from +5 V bus)
W605: 110 mA (typ. 80 mA)
W615: 55 mA (typ. 45 mA)
W625: 110 mA (typ. 80 mA)
Internal current consumption:
(from V+ bus)
0 mA
External current consumption: max. 90 mA, smoothed (W615 only)
Voltage range: RL•20 mA + 10…20 V
 *e.g. RL=500Ω→Ue=20…30V
  RL=0Ω→Ue=10…20V
Terminals: Pluggable 14-pole spring terminal block (4 405 4998 0),
for Ø up to 1.5 mm²,
