Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-79
I/O modules PCD1|PCD2
PCD2.W4x0
5
5.10.1 PCD2.W4x0, analogue outputs, 4 channels, 8 bit resolution
Application
High-speedoutputmodulewith4outputchannelsof8bitseach.Di󰀨erentoutput
signals can be chosen with the aid of jumpers. Suitable for processes in which a
large number of actuators have to be controlled, such as in the chemical industry
and building automation.
Module overview
PCD2.W400: Simplemodulewith4outputchannelsof8bitseach.0 … 10V
PCD2.W410: General purpose module with 4 output channels of 8 bits each.
Signalscanbeselectedfrom0 … 10V,0 … 20mAor4 … 20mA.
Technical data
Number of output channels: 4, short circuit protected
Signal ranges: W400 0 … 10V
W410 0 … 10V*) selectable
 0 … 20mA withjumpers
 4 … 20mA
 *)Factorysetting
Resolution (digital represen-
tation):
8bits(0 … 255)
Conversion time D/A: < 5 µs
Load impedance: for0 … 10V: ≥3kΩ
for0 … 20mA:0 … 500Ω
for4 … 20mA:0 … 500Ω
Accuracy (of output value): for0 … 10V: 1%±50mV
for0 … 20mA:1%±0.2mA
for4 … 20mA:1%±0.2mA
Residual ripple: for0 … 10V: <15mVpp
for0 … 20mA:<50µApp
for4 … 20mA:<50µApp
Temperature error: typically 0.2 %, (across temperature range
0 … +55°C)
Burst protection:
(IEC 801-4)
± 1 kV, with unshielded cables
± 2 kV, with shielded cables
Internal current consumption:
(from +5 V bus)
1 mA
Internal current consumption:
(from V+ bus)
30 mA
External current consump-
tion:
max. 0.1 A (type PCD2.W410 only, for current
outputs)
Terminals:
Pluggable 10-pole screw terminal block
(4 405 4847 0), for wires up to 1.5 mm²
}
