Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
6-41
I/O modules PCD3
PCD3.A410
6
6.5.5 PCD3.A410, 8 digital outputs for 0.5 A each, electrically isolated
Application
Output module, electrically isolated from the CPU, with 8 MOSFET transistor out-
puts, without short-circuit protection. Voltage range 5…32 VDC.
This module is not suitable for triggering the PCA2.D12/D14 display modules.
Technical data
Number of outputs: 8, electrically isolated
Output current: 1…500 mA (leakage current max. 0,1 mA)
Within the voltage range 5…24 VDC, the load resistance should be
atleast48Ω.
Total current per module: 4 A on 100% duty cycle
Operating mode: Source operation (positive switching)
Voltage range: 5…32 VDC, smoothed
10…25 VDC, pulsed
Voltage drop: ≤0.4Vat0.5A
Output delay: Switch-on delay typ. 10 µs
Switch-o󰀨delaytypically50µs
(ohmic load 5…500 mA), longer with inductive load, because of the
protective diode.
Isolation voltage: 1000 VAC, 1 min
Resistance to interference:
acc. to IEC 801-4
4 kV under direct coupling
2 kV under capacitive coupling (whole trunk group)
Internal current consumption:
(from +5 V bus)
1…24 mA
typically 15 mA
Internal current consumption:
(from V+ bus)
0 mA
External current consumption: Load current
Terminals: Plug-in 10-pole spring terminal block (4 405 4954 0) or
pluggable 10-pole screw terminal block (4 405 4955 0),
both for wires up to 2.5 mm²
