I/O modules PCD3
Analogue combined input/output modules, electrically isolated
6
6.13 Analogue combined input/output modules, electrically isolated
PCD3.W525 4 inputs,
14 Bit, 0…10 V, 0(4)…20 mA, Pt1000, Pt500 or Ni1000
(selectable via DIP switch)
and
2 outputs,
12 Bit, 0…10 V or 0(4)…20 mA
(selectable via software (FBox, FB)
Galvanic separation of outputs to Saia PCD
®
, channels themselves not separated
I/O modules and I/O terminal blocks may only be plugged in and removed when the Saia
PCD
®
and the external +24?V are disconnected from the power supply.
