Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-114
I/O modules PCD1|PCD2
PCD2.H110
5
5.16.2 PCD2.H110, general purpose counting / measuring module
up to 100 kHz
Application
Measuring and fast counting module for general counting and simple motion
controltasks;alsoforspecicapplicationssuchasfrequencymeasurement,
period and pulse length measurement, etc. The module is equipped with an FPGA
(Field Programmable Gate Array) and can be programmed for special high volume
applications by using a plug-in PROM.
Technical data
Number of systems: 1
Counting range: 0 … 16,777,215(24bit)
Counting frequency: up to 100 kHz
Data protection: All data in this module are volatile
(non-volatile Saia PCD
®
registers are available).
Digital inputs
Number of inputs:
Terminal 0 = E0
Terminal 1 = E1
Terminal 2 = E2
Terminal 3 = E3
4
Input “A”: for counting and measuring
Input “B”: for counting only
Input “Enable C”: for use as counting module
Input “Enable M”: for use as measuring module
Nominal voltage: 24 VDC
“low”range: -30 … +5V
“high” range: +15 … 30Vfor source operation
Input current: typically 6.5 mA
Inputler: 150 kHz
Circuit type: electrically connected
Digital outputs
Number of outputs:
Terminal 4 A0:
Terminal 5 A1:
2
Output “CCO” (for counter)
Output “TCO” (for measuring functions)
Current range: 5 … 500mA (max.currentleakage1mA)
(min. load resistance 48Ωinvoltage 
  range5 … 24V).
Frequency: ≤100kHz
Voltage range: 5 … 32Vsmoothed,residual ripple max. 10 %
Circuit type: Electrically coupled, not short circuit protected,
positive switching
Voltage drop: typically < 0.5 V at 500 mA
Output delay: < 1 µs, (longer for inductive load due to
protective diode).
Power supply
External supply 5 … 32VDC,(for supply of CCO output only)
Internal current consumption:
(from +5 V bus)
max. 90 mA
Internal current consumption:
(from V+ bus)
0 mA
External current consumption: max. 2 A (all outputs)
Operational conditions
Ambient temperature operation: 0 … +55°Cwithoutforcedventilation,
storage: -20 … +85°C
Noise immunity: EC mark according to EN 61 000-6-3 and EN 61 000-6-2
