SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-88
I/O modules PCD1|PCD2
PCD2.W6x5
5
5.11.1 PCD2.W6x5, analogue outputs, 6 (4) channels,
10 bit resolution, electrical isolated
Application
High-speed output module with galvanic separation of outputs to Saia PCD
®
bus,
forgeneralusewith6(4)channels,eachwith10bitresolution.Di󰀨erentvariants
forvoltage0 … 10V,–10V … +10Vandcurrent0 … 20mAareavailable.
Module overview
Channels Resolution
PCD2.W605: Voltage0 … 10V 6(A0 … A5) 10 mV
PCD2.W615: Current0 … 20 mA 4(A0 … A3) 20 μA
PCD2.W625: Voltage–10 … +10V 6(A0 … A5) 20 mV
Technical data
Output ranges: see module overview
Galvanic separation: 500 V, galvanic separation of outputs to Saia PCD
®
,
channels themselves not separated
Resolution (digital representation): 10bits(0 … 1023)
Loadresistance: W605:  >3kΩ
W615:  <500Ω*
W625:  >3kΩ
Accuracy at 25 °C W605: ± 0.4 %
W615: ± 0.7 %
W625: ± 0.4 %
Temperatureerror(0 … +55°C) ± 0.25 %, 100 ppm/K or 0.01 %/K
Short circuitprotection: yes (permanent)
EMC protection: acc. to standards ENV 50141, EN 55022,
EN 61 000-4-2, EN 61 000-4-4, EN 61 000-4-5
Timeconstantofoutputlter: W605: typically 1 ms
W615: typically 0.3 ms
W625: typically 1 ms
Internal current consumption:
(from +5 V bus)
W605: 110 mA (typ. 80 mA)
W615: 55 mA (typically 45 mA)
W625: 110 mA (typically 80 mA)
Internal current consumption:
(from V+ bus)
0 mA
External current consumption: max. 90 mA, smoothed
Voltagerange:  RL•20mA +10 … 20V
  *E.g. RL=500Ω→Ue=20 … 30V
   RL=0Ω→Ue=10 … 20V
Terminals: Pluggable 14-pole spring terminal block
(4 405 4998 0), for wires up to 1.5 mm²
