6.1.3 External input voltage
Type Description External input voltage or voltage range
Digital input modules
PCD3.E110 8 inputs 8 ms 24 VDC smoothed or pulsed
PCD3.E111 8 inputs 0.2 ms 24 VDC smoothed, max.ripple 10%
PCD3.E112 8 inputs 9 ms 12 VDC smoothed, max.ripple 10%
PCD3.E116 8 inputs 0.2 ms 5 VDC smoothed, max.ripple 10%
PCD3.E160 16 inputs 8 ms 24 VDC smoothed or pulsed
PCD3.E165 16 inputs 8 ms 24 VDC smoothed or pulsed
PCD3.E166 16 inputs 0.2 ms 24 VDC smoothed or pulsed
PCD3.E500 6 inputs 115/230 VAC
PCD3.E610 8 inputs 10 ms 24 VDC smoothed or pulsed
PCD3.E613 8 inputs 9 ms 48 VDC smoothed or pulsed
Digital output modules
PCD3.A200 4 make cont. 2 A 250 VAC, 50 VDC
PCD3.A210 4 break contacts 2 A 250 VAC, 50 VDC
PCD3.A220 6 make cont. 2 A 250 VAC, 50 VDC
PCD3.A251 6 ch/over + 2 make cont. 48 VAC, 50 VDC
PCD3.A300 6 outputs 2 A 5…32 VDC smoothed, or 10…25 VDC pulsed
PCD3.A400 8 outputs 0.5 A 5…32 VDC smoothed, or 10…25 VDC pulsed
PCD3.A410 8 outputs 0.5 A 5…32 VDC smoothed, or 10…25 VDC pulsed
PCD3.A460 16 outputs 0.5 A 10…32 VDC smoothed, max.ripple 10%
PCD3.A465 16 outputs 0.5 A 10…32 VDC smoothed, max.ripple 10%
PCD3.A810 4 outputs 250 VAC, 50 VDC
PCD3.A860 2 inputs, 2 outputs 250 VAC, 24 VDC
PCD3.B100 2 I, 2 O, 4 selectable I/O 24 VDC smoothed or pulsed
PCD3.B160 16I/Ocongurable 18…30 VDC smoothed or pulsed
Analogue input modules
PCD3.W200 8 inputs 10 bit
PCD3.W210 8 inputs 10 bit
PCD3.W220 8 inputs 10 bit
PCD3.W300 8 inputs 12 bit
PCD3.W310 8 inputs 12 bit
PCD3.W340 8 inputs 12 bit
PCD3.W350 8 inputs 12 bit
PCD3.W360 8 inputs 12 bit
PCD3.W380 8 inputs 13 bit
PCD3.W3x5 7 inputs 12 bit
Analogue output modules
PCD3.W400 4 outputs 8 bit
PCD3.W410 4 outputs 8 bit 24 VDC smoothed or pulsed
PCD3.W600 4 outputs 12 bit
PCD3.W610 4 outputs 12 bit 24 VDC smoothed or pulsed
PCD3.W6x5 6/4 outputs 10 bit 24 VDC smoothed or pulsed
PCD3.W500 2 O 12 bit + 2 I 12 bit
PCD3.W525 4 O 12 bit + 2 I 14 bit
PCD3.W7x0 Weighing modules
PCD3.W745 Thermocouple module
PCD3.W800 Manual control module
Counting and motion control I/O modules
PCD3.H100 Counting module 5…32 VDC smoothed, max.ripple 10%
PCD3.H110 Counting module 5…32 VDC smoothed, max.ripple 10%
PCD3.H150 SSI interface module 10…32 VDC smoothed, max.ripple 10%
PCD3.H210 Motion control module 5…32 VDC smoothed, max.ripple 10%
PCD3.H310 Motion control module 24 V (19…32 VDC smoothed, max.ripple 10%)
PCD3.H311 Motion control module 5 VDC
