Digital output modules for manual operation, electrically isolated
6
6.6 Digital output modules for manual operation, electrically isolated
PCD3.A810 Manual control module, with 2 changeover and 2 make con-
tacts
PCD3.A860 Light and shade module, with 2 make contacts
The Annex, Section A.3 "Relay contacts" contains measurement details and suggested wir-
ing for the relay contacts.
Forsafeswitchingandalongservicelife,theseguresmustbeobserved.
