I/O modules PCD3
PCD3.W745
6
6.16 General-purpose temperature modules
PCD3.W745 Thermocouple modules, 4-channel
Supported temperature sensors are:
● Thermocouples – TC type J,K
● Resistance thermometer (RTD) – RTD type Pt 100, Pt 1000, Ni 100, Ni1000
I/O modules and I/O terminal blocks may only be plugged in and removed when the Saia
PCD
®
and the external +24?V are disconnected from the power supply.
6.16.1 PCD3.W745
The PCD3.W745 module is described in Manual 26-796.
