5.5.5 PCD2.A410, 8 digital outputs for 0.5 A each, electrically isolated
Application
Output module, electrically isolated from the CPU, with 8 MOSFET transistor out-
puts,withoutshort-circuitprotection.Voltagerange5 … 32VDC.
This module is not suitable for triggering the PCA2.D12/D14 display modules.
Technical data
Number of outputs: 8, electrically isolated
Output current: 1 … 500mA(leakagecurrentmax.0,1mA)
Withinthevoltagerange5 … 24VDC,theloadresis-
tanceshouldbeatleast48Ω.
Total current per module: 4 A on 100 % duty cycle
Operating mode: Source operation (positive switching)
Voltage range: 5 … 32VDC,smoothed
10 … 25VDC,pulsed
Voltage drop: ≤0,4Vat0,5A
Output delay: Switch-on delay typically 10 µs
Switch-o󰀨delaytypically50µs
(ohmicload5 … 500mA),longerwithinductiveload,
because of the protective diode.
Isolation voltage: 1000 VAC, 1 min
Resistance to interference:
acc. to IEC 801-4
4 kV under direct coupling
2 kV under capacitive coupling (whole trunk group)
Internal current consump-
tion:
(from +5 V bus)
1 … 24mA
typically 15 mA
Internal current consump-
tion:
(from V+ bus)
0 mA
External current consump-
tion:
Load current
Terminals:
Pluggable 10-pole screw terminal block
(4 405 4847 0), for wires up to 1.5 mm²
