SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-87
I/O modules PCD1|PCD2
Analogue output modules with electrically isolation
5
5.11 Analogue output modules with electrically isolation
PCD2.W605 6 analogue outputs 10 bit resolution, 0 … 10 V
PCD2.W615 4 analogue outputs 10 bit resolution, 0 … 20 mA
PCD2.W625 6 analogue outputs 10 bit resolution, –10 V … +10 V
Galvanic separation of outputs to Saia PCD
®
, channels themselves not separated
I/O modules and I/O terminal blocks may only be plugged in and removed when the
Saia PCD
®
and the external +24 V are disconnected from the power supply.
