Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-121
I/O modules PCD1|PCD2
PCD2.H210
5
5.18.1 PCD2.H210, Motion control module for stepper motors
Application
The PCD2.H210 Module provides fully autonomous control and monitoring of
stepper motor travel, with run-up and braking ramps. The commands for stepper
motor motion cycles are transmitted to the module by function blocks in the user
program.
Duringmotion,theSMprocessormonitorsthefrequencyproleandtheaccelera-
tion and braking ramps to move the axis to the destination position without loss of
steps. Each module controls an independent axis. The module supplies a mono-
phase pulse string which is conveyed to a suitable electronic drive. The module
has 4 inputs and 4 outputs.
Technical data
Number of axes: 1
Positioning distance (counting
range):
0 … 16,777,215(24bit)
Frequency ranges (selecta-
ble)*):
9.5 … 2,431Hz
19 … 4,864Hz
38 … 9,727Hz
76 … 19,454Hz
Acceleration*): 0.6 … 1224kHz/s,non-linearrangedivisiondependingon
the selected frequency range
Prolegenerator: with symmetrical acceleration and braking ramps
Data protection: All data in this module are volatile
(non-volatile Saia PCD
®
registers are available).
Digital inputs
Number of inputs:
Terminal 0 = E0
Terminal 1 = E1
Terminal 2 = E2
Terminal 3 = E3
4
congurableasemergencystoporforgeneraluse
congurableaslimitswitchLS1orforgeneraluse
congurableasreferenceswitchorforgeneraluse
congurableaslimitswitchLS2orforgeneraluse
Nominal voltage: 24 VDC
“low”range: -30 … +5V
“high” range: +15 … 30Vfor source operation only,
for safety reasons, normally-closed contacts (negative
logic) should be used
Input current: typically 6.5 mA
Inputler: < 1ms
Circuit type: electrically connected
Digital outputs
Number of outputs:
Terminal 4 A0:
Terminal 5 A1:
Terminal 6 A2:
Terminal 7 A3:
4
Output “PUL” (pulses for motor)
Output “DIR” (direction of motor rotation)
programmable as required
programmable as required
Switching capacity: 0.5Aeachintherange5 … 32V,residualripplemax.10%
Short circuit protection: no
Electrical isolation: no
