Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
6-1
I/O modules PCD3
Introduction to I/O modules
6
6 Input/output (I/O) modules for PCD3
6.1 Introduction to I/O modules
There are over 50 I/O modules available for digital and analogue I/Os, counters
etc. If they are connected to a Saia PCD
®
, programming (FBs and FBoxes) is done
in the usual way. If they are connected to a RIO system, nothing particular needs
to be programmed on the Master PCD. The RIO sends the correct values to the
Master.
Type
I/Os
Description
Input/
output signal
range
I/O
connector type ³
Page
Digital input modules
PCD3.E110 8 I 8 inputs 8 ms 24 VDC A / B 6-12
PCD3.E111 8 I 8 inputs 0.2 ms 24 VDC A / B 6-12
PCD3.E112 8 I 8 inputs 9 ms 12 VDC A / B 6-12
PCD3.E116 8 I 8 inputs 0.2 ms 5 VDC A / B 6-12
PCD3.E160 16 I 16 inputs 8 ms,
connection via 34-pole ribbon connector
24 VDC D
7
) 6-14
PCD3.E161 16 I 16 inputs 0.2 ms,
connection via 34-pole ribbon connector
24 VDC D
7
) 6-14
PCD3.E165 16 I 16 inputs 8 ms, connection via 24-pole cage
clamp terminal block
24 VDC C 6-16
PCD3.E166 16 I 16 inputs 0.2 ms, connection via 24-pole
cage clamp terminal block
24 VDC C 6-16
Digital input modules, electrically isolated from the I/O Bus
PCD3.E500 6 I 6 inputs 20 ms, electrically isolated 115/230 VAC A / B 6-19
PCD3.E610 8 I 8 inputs 10 ms, electrically isolated 24 VDC A / B 6-21
PCD3.E613 8 I 8 inputs 9 ms, electrically isolated 48 VDC A / B 6-21
Digital output modules
PCD3.A300 6 O 6 outputs 2 A 24 VDC A / B 6-24
PCD3.A400 8 O 8 outputs 0.5 A 24 VDC A / B 6-26
PCD3.A460 16 O 16 outputs 0.5 A,
connection via 34-pole ribbon connector
24 VDC D
7
) 6-28
PCD3.A465 16 O 16 outputs 0.5 A,
connection via 24-pole spring terminal block
24 VDC C 6-30
