SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
6-2
I/O modules PCD3
Introduction to I/O modules
6
Type
I/Os
Description
Input/
output signal
range
I/O
connector type ³
Page
Digital output modules, electrically isolated from the I/O Bus
PCD3.A200 4 O 4 make contacts 2 A 250 VAC
50 VDC
A / B 6-33
PCD3.A210 4 O 4 break contacts 2 A 250 VAC
50 VDC
A / B 6-35
PCD3.A220 6 O 6 make contacts 2 A 250 VAC
50 VDC
A / B 6-37
PCD3.A251 8 O 6 changeover + 2 make contacts 2 A,
connection via 24-pole spring terminal block
48 VAC
50 VDC
C 6-39
PCD3.A410 8 O 8 outputs 0.5 A, electrically isolated 24 VDC A / B 6-41
Digital output modules for manual operation
PCD3.A810 4 O Manual control module, 2 changeover con-
tacts + 2 make contacts, 2 A, 5(6) A
50 VDC
250 VAC
F 6-44
PCD3.A860 2I+2O Light and shade module, 2 outputs
12 A/250 VAC, 2 inputs 24 VDC
250 VAC
24 VDC
G
H
6-48
Digital combined input/output modules
PCD3.B100 2I+2O
+4 I/O
2 inputs, 2 outputs, 4 selectable as inputs or
outputs
24 VDC A / B 6-55
PCD2.B160 16 I/O Inblocksof4congurable 18…30 VDC 2× K 7
Analogue input modules
PCD3.W200 8 I 8 inputs 10 bit 0…10 V A / B 6-59
PCD3.W210 8 I 8 inputs 10 bit 0…20 mA A / B 6-59
PCD3.W220 8 I 8 inputs 10 bit Pt/Ni1000 A / B 6-59
PCD3.W300 8 I 8 inputs 12 bit 0…10 V A / B 6-65
PCD3.W310 8 I 8 inputs 12 bit 0…20 mA A / B 6-65
PCD3.W340 8 I 8 inputs 12 bit, jumper selectable 0…10 V,
0…2.5 V
0…20mA,
Pt/Ni1000
A / B 6-65
PCD3.W350 8 I 8 inputs 12 bit Pt/Ni 100 A / B 6-65
PCD3.W360 8 I 8 inputs 12 bit, resolution ‹ 0.1 °C Pt1000 A / B 6-65
PCD3.W380 8 I 8 analogue inputs 13 bit,
congurationviasoftware
Diverse 2× K 8
