6.6.1 PCD3.A810, Digital manual control module with 4 relays,
2 with changeover, 2 with make contacts
Application
The module has 4 relay outputs: 2 changeover and 2 make contacts. Each chan-
nel has a switch with the settings MAN 1, AUTO, MAN 0. On MAN 0, the relay is
alwaysswitchedo󰀨;onMAN1itisalwaysswitchedon;onAUTOtheswitchstate
isdenedbytheapplicationprogram.Thisisnotanemergencymodulethatwill
work even when the Saia PCD
®
isswitchedo󰀨(ordefective).Theexternal24V
supply feeds only the relays, and not the logic. For space reasons, there is no inte-
grated contact protection (for emergency and manual operation, see also section
3.20).
Technical data
Number of outputs: 4, 2 changeover (O 0, 1) and
2 make contacts (O 2, 3)
Switching capacity
Relay type changeover (O 0, 1): RE 01 4024, SCHRACK
Operating mode: > 12 V, > 100 mA
Max. switching current: 5 A, 250 VAC AC1
Contactlifetime*):
5 A, 250 VAC AC1 1.5 × 10
5
operations
2 A, 250 VAC AC15 1.2 × 10
5
operations
cosφ=0.3
Relay type make (O 2, 3): RE 03 0024, SCHRACK
Operating mode: > 12 V, > 100 mA
Max. switching current: 6 A 250 VAC AC1
Contactlifetime*):
6 A, 250 VAC AC1 1 × 10
5
operations
2 A, 250 VAC AC11 4 × 10
5
operations
*) therearenosuppressorsttedtothemodule;thesemustbeprovidedexternally  
.
Switching delay: typically 5 ms at 24 VDC
Internal current consumption:
(from +5 V bus)
max. 45 mA
Internal current consumption:
(from V+ bus)
0 mA
External current consumption: max. 45 mA
Relay coil supply: nom. 24 VDC smoothed or pulsed, reverse voltage
protected
Voltage tolerance, dependent on ambient
temperature:
20°C: 21.5…32 VDC
30°C: 21.9…32 VDC
40°C: 22.3…32 VDC
50°C: 22.8…32 VDC
Isolation
Withstand voltage - coil contacts
Withstand voltage - open contact circuit
4 kV (relay details)
1 kV (relay details)
Terminals: Plug-in 12-pole spring terminal block
(4 405 4936 0), for Ø up to 1.5 mm²,
or as above with 12 grouped strands, numbered,
2.5 m long (PCD3.K810)
The supply to the relay coils is not electrically isolated from the Saia PCD
®
side.
GeneraltechnicalspecicationsasperCL-EPC-015Rev.02
