PCD2.W380 & PCD3.W380
PCD2/3.W380,8analogcongurableinputs
8
8.1.6 Congurable digital lters
Eachchannelcanbeconguredwithadigitallter.Fourpossibilitiesareavailable:
● Disabled: Eachchannelvalueisupdatedinbu󰀨erevery680μs
(f = 1.47 kHz)
● 3 ms: Mean of 4 cycles, value updated every 2.72 ms
(f = 367 Hz)
● 6 ms: Mean of 8 cycles, value updated every 5.44 ms
(f = 184 Hz)
● 12 ms: Mean of 16 cycles, value updated every 10.88 ms
(f = 92 Hz)
8.1.7 Out of range indication
The module has an out of range indication. This information can be read in the
registers “OutOfRange”.
The table below shows the values setting the bits “Out Of Range.
N/A means not available.
Mode “Out of range” bit set…
Limit min Limit max
Voltage –10 V … +10 V N/A N/A
Current –20 mA … +20 mA –20’002 uA +20’002 uA
Resistance 0 …2'500Ω N/A 2518.7Ω
Resistance 0 …300kΩ N/A 302’010Ω
Pt 1000 –50.0 °C +408.7 °C
Ni 1000 –50.0 °C +210.3 °C
Ni 1000 L&S –30.0 °C +130 °C
Diode 0 … 5’000 mV k. A. 4’999 mV
Table 5: Limits for Out Of Range
