Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
6-125
I/O modules PCD3
PCD3.H31x
6
6.17.5 PCD3.H31x, motion control module for servo-motors, 1-axis encoder
Application
The PCD3.H31x motion control module is an intelligent I/O module. The module is
used to position a single axis with variable speed control DC or AC servomotors.
This requires the drive unit to have a power stage and incremental shaft encoder
for capturing position or speed.
Each module contains a single-chip processor that independently controls every
movement according to parameters supplied by the user program (velocity,
acceleration and destination position). The axes are controlled independently of
each other, which means that no interpolation is possible to trace curved paths.
On the other hand, linking of multiple axes (point-point) in quasi-synchronous
operation cane be programmed.
This I/O module cannot currently be used with the PCD3 RIO head station
Technical data
Number of axes: 1
Motion parameters
31-bit registers are used for destination position, velocity and acceleration, numerical range
± 2
30
Position:
Resolution selectable (depending on mechanical factor)
Velocity:
Resolution selectable (depending on mechanical factor)
Acceleration:
Resolution selectable (depending on mechanical factor)
PID controller: Sampletime341μs,programmableproportional,integraland
di󰀨erentialfactors.Sampletimefordi󰀨erentialpartcanbepro-
grammed separately.
Analogue controller output:
Velocity set point ±10 V (resolution 12 bit)
Counting frequency:
max. 50 kHz
Digital inputs to PCD3.H310
Number of inputs: 1 encoder A, B, IN, 1 reference input
Nominal voltage: 24 V typically
“low” range: 0…+4 V
“high” range: +15…30 V for source operation only,
Input current: typically 6 mA
Circuit type: electrically connected
Reaction time: 30 µs
Encoder frequency: max. 100 kHz
Digital inputs to PCD3.H311
Number of inputs: 1 encoder A, /A, B, /B, IN, /IN, (no reference input)
Input voltage: 5 V typically
Signal level: antivalent inputs according to RS-422
Hysteresis: max. 200 mV
Line termination resistance: 150Ω
Encoder frequency: max. 100 kHz
Analogue outputs for PCD3.H310/311
Analogue controller output: resolution 12 bit (with sign bit)
Short circuit protection: yes
Electrical isolation: no
Outputvoltage*):
±10 V, accuracy of adjustment ±5 mV
