I/O modules PCD1|PCD2
Combined analogue input/output modules with galvanic isolation
5
5.13 Combined analogue input/output modules with galvanic isola-
tion
PCD2.W525 4 inputs,
14 bits, 0…10 V, 0(4)…20 mA, Pt 1000, Pt 500 or Ni 1000
(selectable by DIP switch)
and
2 outputs, 12 bits, 0…10 V or 0(4)…20 mA
(selectable by software (FBox, FB)
Galvanic separation of outputs to Saia PCD
®
, channels themselves not sepa-
rated
I/O modules and I/O terminal blocks may only be plugged in and removed when
the Saia PCD
®
and the external +24 V are disconnected from the power supply.
