SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-6
I/O modules PCD1|PCD2
Overview
5
Type Description Page
PCCD2 fast counting I/O modules
PCD2.H100 Counting module up to 20 kHz 5–109
PCD2.H110 General purpose module up to 100 kHz 5–114
PCD2 SSI encoder modules
PCD2.H150 SSI interface module 5-117
PCD2 Positioning modules for stepping motors
PCD2.H210 Motion control module for stepper motors 5-121
Positioning modules for servo-drives
PCD2.H310 Motion control module for servo-motors
1-axis encoder 24 VDC
5-125
PCD2.H311 Same as H310, but 1-axis encoder 5 VDC 5-125
PCD2.H320 Motion control module for servo-drives
2-axis with encoder 24 VDC
5-129
PCD2.H322 Same as H320, but 1-axis (slave operation) 5-129
PCD2.H325 Motion control module for servo-drives, 2-axis with 5 V
and SSI absolute value encoder
5-129
PCD2.H327 Same as H325, but 1-axis (slave operation) 5-129
