SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-5
I/O modules PCD1|PCD2
Overview
5
Type Desig-
nation
No.
I/Os
or
mod
Description Input/output
signal range
Page
PCD2 weighing modules
PCD2.W710 1 I 1 1-channel weighing module for
4/6-wire weighing cells
5–106
PCD2.W720 2 I 2 2-channel weighing module for
4/6-wire weighing cells
5–106
PCD2 thermocouple modules
PCD2.W745 4 I 4 Thermocouple module for J, K …
thermocouples
2
)
5–107
1) Galvanic separation of outputs to Saia PCD
®
, channels themselves not separated
2) Non-pluggable cage clamp terminals
