Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-4
I/O modules PCD1|PCD2
Overview
5
Type Desig-
nation
No.
I/Os
or
mod
Description Input/output
signal range
Page
PCD2 analogue output modules
PCD2.W400 4 O 4 4 analogue outputs 8 bit 0 … 10V 5-79
PCD2.W410 4 O 4 4 analogue outputs 8 bit,
jumper selectable
0 … 10V,
0 … 20mA,
4 … 20mA
5-79
PCD2.W600 4 O 4 4 analogue outputs 12 bit 0 … 10V 5-83
PCD2.W610 4 O 4 4 analogue outputs 12 bit,
jumper selectable
0 … 10V,
–10 V..+10 V
0 … 20mA,
4 … 20mA
5-83
PCD2 analogue output modules, electrically isolated
1
)
PCD2.W605 6 O 6 6 analogue outputs 10 bit 0 … 10V 5-88
PCD2.W615 4 O 4 4 analogue outputs 10 bit 0 … 20mA 5-88
PCD2.W625 6 O 6 6 analogue outputs 10 bit –10 … +10V 5-88
PCD2 analogue combined input/output modules
PCD2.W500 2I +
2O
4 2 analogue inputs 12 bit
+ 2 analogue outputs 12 bit
0 … 10V,
–10 … +10V
5-92
PCD2.W510 2I +
2O
4 2 analogue inputs 12 bit
+ 2 analogue outputs 12 bit
0 … +20mA
-20 … +20mA
5-92
PCD2 analogue combined input/output modules, electrically isolated
1
)
PCD2.W525 4 E
+ 2 A
4 4 analogue inputs 14 bit
+ 2 analogue outputs 12 bit
0 … 10V,
0(4) … 20mA
Pt 500 / 1000,
Ni 1000
0 … 10V,
0(4) … 20mA
5-98
