SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
5-3
I/O modules PCD1|PCD2
Overview
5
Type Desig-
nation
No.
I/Os
or
mod
Description Input/output
signal range
Page
PCD2 analogue input modules
PCD2.W100 4 I 4 Analogue inputs 12 bit 0 … 10V,
–10 … +10V
5-53
PCD2.W105 4 I 4 Analogue inputs 12 bit 0 … +20mA
-20 … 0mA
-20 … +20mA
5-53
PCD2.W110 4 I 4 Analogue inputs 12 bit Pt 100 5-56
PCD2.W111 4 I 4 Analogue inputs 12 bit Ni 100 5-56
PCD2.W112 4 I 4 Analogue inputs 12 bit Pt 1000 5-56
PCD2.W113 4 I 4 Analogue inputs 12 bit Ni 1000 5-56
PCD2.W114 4 I 4 Analogue inputs 12 bit Pt 100 5-56
PCD2.W200 8 I 8 8 analogue inputs 10 bit 0 … 10V 5-61
PCD2.W210 8 I 8 8 analogue inputs 10 bit 0 … 20mA 5-61
PCD2.W220 8 I 8 8 analogue inputs 10 bit Pt/Ni 1000 5-61
PCD2.W220Z02
8 I 8 8 analogue inputs 10 bit NTC 10 5-61
PCD2.W220Z12
8 I 8 8 analogue inputs 10 bit 4×0 … 10V
4×Pt/Ni 1000
5-61
PCD2.W300 8 I 8 8 analogue inputs 12 bit 0 … 10V 5-67
PCD2.W310 8 I 8 8 analogue inputs 12 bit 0 … 20mA 5-67
PCD2.W340 8 I 8 8 analogue inputs 12 bit,
jumper selectable
0 … 10V,
0 … 2,5V
0 … 20mA,
Pt/Ni 1000
5-67
PCD2.W350 8 I 8 8 analogue inputs 12 bit Pt/Ni 100 5-67
PCD2.W360 8 I 8 8 analogue inputs 12 bit,
resolution ‹ 0.1 °C
Pt 1000 5-67
PCD2.W380 8 I 8 8 analogue inputs 13 bit,
congurationviasoftware
diverse 8
PCD2 analogue input modules, electrically isolated
1
)
PCD2.W305 7 I 7 7 analogue inputs 12 bit 0 … 10V 5-74
PCD2.W315 7 I 7 7 analogue inputs 12 bit 0 … 20mA 5-74
PCD2.W325 7 I 7 7 analogue inputs 12 bit –10 … +10V 5-74
1) galvanic separation of outputs to Saia PCD
®
, the channels themselves are not separated against
each other
