SBC PCD2 Series User Manual

Saia-Burgess Controls AG
Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
8-6
PCD2.W380 & PCD3.W380
PCD2/3.W380,8analogcongurableinputs
8
Themoduleo󰀨ersthepossibilitytouseNTCtemperaturesensors.Thecorre-
spondinginputmustbeconguredinmode“Resistance0…300kΩ”.
Mode
„Resistance 0…300 kΩ“
Resolution
[Bit]
Resolution [measure] Accuracy
(@ T
Ambient
= 25 °C)
Display
NTC10k
1)
13 Bit –40…+120 °C: 0,05…0,1 °C –20…+60 °C: ± 0,6 °C
–30…+80 °C: ± 1,0 °C
–40…+120 °C: ± 2,8 °C
–400…1200
2)
NTC20k
3)
13 Bit –10…+80 °C:
–20…+150 °C:
0,02…0,05 °C
< 0,15 °C
–15…+75 °C: ± 0,6 °C
–20…+95 °C: ± 1,0 °C
+95…+120 °C: ± 2,5 °C
+120…+150 °C: ± 5,8 °C
–200…1500
4)
¹ ThetemperaturecurvesfortheNTC10karenotstandardizedandmaybedi󰀨erentforeachmanufacturer.
For this reason, the curves can be loaded by the user program using the linearization FBox. The curve of
theNTC10kfromProdualisavailableinaCSVleandcanbedownloadedfromtheSupportWebsite.
² ThisistheoutputvalueoftheFBoxforlinearization.Themodulegivesaresistance0…300’000Ω.
³ For the same reason of NTC10k, the curve of the NTC20k from Honeywell can be downloaded from the
Support Website.
⁴ ThisistheoutputvalueoftheFBoxforlinearization.Themodulegivesaresistance0…300’000Ω.
Table3:InputsspecicationsforNTC10kandNTC20k
For an example of the utilization of a NTC sensor, please see the chapter 4 “Ex-
ample of linearization”.
Withaninputconguredin“Diode0…5000mV”,itispossibletouseintegrated
circuit temperature sensors operating as a 2-terminal zener. A typical sensor for
this measurement is the LM235 for example.
Mode
„Resistance
0...300 kΩ“
Resolution
[Bit]
Resolution [measure] Accuracy
(@ T
Ambient
= 25 °C)
Display
LM235 12 Bit –40…+125 °C: 0,12 °C 0,2 % of measured value ±1,0 °C –400…1250
1
1
This is the output value of the FBox for linearization. The module gives a voltage 5’000mV.0 … 5’000 mV.
Table4:InputsspecicationsforLM235
For an example of the utilization of a LM235 sensor, please see the chapter 4
“Example of linearization”.
