Manual I/O-modules for PCD1 │ PCD2 series │ Document 27-600 – Release ENG09 │ 2019-05-01
9-4
PCD2.G200
Specications
9
Technical data
ANALOGUE INPUTS
Number of inputs 8
Conquration AI0 / AI1:
AI2 / AI3 / AI4 / AI5:
AI6 / AI7:
0…10 V
Dip Switch selectable
PT/NI1000
Galvanic separation no
Signal ranges 0…10VResolution*)2.44mV
0…20mA,Resolution*)4.88μA
*)Resolution=valueofleastsignicantbit(LSB)
Resolution (digital representation) 12bits(0…4095)rsp.directlyin1/10°Corin0.1Ω
Connection technique for sensors 2-wires (passiv input)
Measuring principle Single ended
Input resistance 10 V range:
20 mA range:
PT/NI1000:
20kΩ
125Ω
7.5kΩ
Inputlter typ.
typ.
10 ms (0…10 V)
20ms(0…20mA;PT/NI1000)
Input ranges for temperature sen-
sors
PT1000:
NI1000:
NI1000L&S:
Resistance:
Resistance:
– 50…+400°C
– 60…+200°C
– 60…+200°C
0…2500Ω
0…300kΩ
Accuracy at 25°C ± 0.5% (±0.4% ±4 LSB)
Temperature error (0…+55°C) ± 0.25%
Overrange protection 10 V range: + 35 V (39 V TVS Diode)
20 mA range: no protection ( 40 mA max.)
Terminals 1 plug-in spring-load terminal block, 10-pole,
3.5 mm for wiring up to 1 mm
2
, orange
ANALOGUE OUPUTS
Number of outputs 8
Galvanic separation no
Signal ranges 0…10VResolution10mV,LSB(leastsignicantbit)
Resolution (digital representation) 10 bits (0…1023)
Accuracy at 25°C ± 0.5% ± 50 mV
Temperature error (0…+55°C) ± 0.25%
Load resistance min.3kΩ
Short-circuit protection yes, permanent
Terminals 1 plug-in spring-load terminal block, 10-pole,
3.5 mm for wiring up to 1 mm
2
, orange
Table 2: Technical data of the module
