Multi-speed parameter group 04
PARAMETER DESCRIPTION 98
5.5 Multi-speed parameter group 04
Group
Parameter
Number
Name
Setting Range
Default
Page
04-00
P.4
Speed 1 (high speed)
0～650.00Hz
60.00Hz
100
04-01
P.5
Speed 2 (medium speed)
0～650.00Hz
30.00Hz
100
04-02
P.6
Speed 3 (low speed)
0～650.00Hz
10.00Hz
100
04-03
P.24
Speed 4
0～650.00Hz
99999
100
99999: Off
04-04
P.25
Speed 5
Same as 04-03
99999
100
04-05
P.26
Speed 6
Same as 04-03
99999
100
04-06
P.27
Speed 7
Same as 04-03
99999
100
04-07
P.142
Speed 8
Same as 04-03
0.00Hz
100
04-08
P.143
Speed 9
Same as 04-03
99999
100
04-09
P.144
Speed 10
Same as 04-03
99999
100
04-10
P.145
Speed 11
Same as 04-03
99999
100
04-11
P.146
Speed 12
Same as 04-03
99999
100
04-12
P.147
Speed 13
Same as 04-03
99999
100
04-13
P.148
Speed 14
Same as 04-03
99999
100
04-14
P.149
Speed 15
Same as 04-03
99999
100
04-15
P.100
Programmed operation
minute / second selection
0: Select minute as the time increment.
1
102
1: Select second as the time increment.
04-16
P.121
Run direction in each section
0～255
0
102
04-17
P.122
Programmed operation cycle
selection
0:Off
0
102
1～8: Start cycle from the set section.
04-18
P.123
Programmed operation
acceleration / deceleration
time setting selection
0: Acceleration time is 01-06(P.7),
deceleration time is 01-07(P.8).
0
102
1: Acceleration and deceleration time is set
by 04-35(P.111)～04-42(P.118).
04-19
P.131
Programmed operation mode
speed 1
0～650.00Hz
0.00 Hz
102
04-20
P.132
Programmed operation mode
speed 2
0～650.00Hz
0.00 Hz
102
04-21
P.133
Programmed operation mode
speed 3
0～650.00Hz
0.00 Hz
102
04-22
P.134
Programmed operation mode
speed 4
0～650.00Hz
0.00 Hz
102
04-23
P.135
Programmed operation mode
speed 5
0～650.00Hz
0.00 Hz
102
04-24
P.136
Programmed operation mode
speed 6
0～650.00Hz
0.00 Hz
102
04-25
P.137
Programmed operation mode
speed 7
0～650.00Hz
0.00 Hz
102
04-26
P.138
Programmed operation mode
speed 8
0～650.00Hz
0.00 Hz
102
