Name of each component
INVERTER INTRODUCTION 18
3.4 Name of each component
3.4.1 Frame A/B
Fan lid
Product nameplate
Upper lid
Control circuit sticker
Lower lid
External keypad connector
Mounting holes
3.4.2 Frame C/D
Fan lid
Product nameplate
Upper lid
Control circuit sticker
External keypad connector
Mounting holes
foundation
Warning nameplate
Main-circuit sticker
membrane switch
knobne switch
