Shihlin electric SC3 Series User Manual

Digital input/ output parameter group 03
PARAMETER DESCRIPTION 93
5.4.2 Digital output terminals function selection
 Detect some information that occurs during the operation of the inverter.
Parameter
Name
Default
Setting Range
Content
03-11
P.85
Terminal A-C
output function
5
0
RUN(Output when inverter running): Output signal when
inverter run above starting frequency
1
SU(Output when reach target frequency): Output signal
when the output frequency reaches target frequency
2
FU（Output when reach certain frequency）: Output signal
when detecting operation above specified frequency
3
OL（Output when overload）： Output signal when current
limit function is activated
4
OMD（Output when output current is zero）: When the output
current of the inverter is lower than the set value in 03-23
(P.62) for a period of time (03-24 (P.63)), OMD will output a
signal
5
ALARM（Output when alarm）
6
PO1（Output when in program operation step）
7
PO2（Output when in program operation cycle）
8
PO3（Output when in program operation pause）
9~10
Reserved
11
OMD1(Output when output current is zero 1)：When the
output frequency of the inverter reaches the target
frequency and the output current is lower than the setting
value in 03-23 (P.62) for a period of time (setting of 03-24
(P.63)), OMD1 will output a signal
12
OL2(Output when over torque)：If 06-10 (P.260)=1, when
the over-torque signal is output, inverter will alarm OL2 and
stop running; if 06-10 (P.260)=0, when the over-torque
signal is output, the inverter will not alarm OL2 and
continues to run.
13～16
Reserved
17
RY(Output when inverter is powered on and no alarm)
18
Output when it’s time for maintenance
19-40
Reserved
41
PID feedback disconnection (AErr) alarm
42
Fire mode indication
Digital output terminals function selection
 Terminal A-C default value 03-11(P.85) is 5 which means “ALARM”. If 03-11(P.85) value is changed, terminal
function will change as shown in table above.
Setting
