Shihlin electric SC3 Series User Manual

Multi-speed parameter group 04
PARAMETER DESCRIPTION 102
5.5.2 Programmed operation mode
 The application of this parameter can be used as the operation process control for general small machinery, food
processing machinery and washing equipment, which can replace some traditional relays, switches, timer and
other control circuit, etc.
Parameter
Name
Default
Setting Range
Content
04-15
P.100
Programmed operation
minute / second selection
1
0
Select minute as the time increment.
1
Select second as the time increment.
04-16
P.121
Run direction in each section
0
0～255
---
04-17
P.122
Programmed operation cycle
selection
0
0
Off
1～8
Start cycle from the set section.
04-18
P.123
Programmed operation
acceleration / deceleration
time setting selection
0
0
Acceleration time is 01-06(P.7), deceleration time
is 01-07(P.8).
1
Acceleration and deceleration time is set by
04-35(P.111)～04-42(P.118).
04-19
P.131
Programmed operation mode
speed 1
0.00Hz
0～650.00Hz
---
04-20
P.132
Programmed operation mode
speed 2
0.00Hz
0～650.00Hz
---
04-21
P.133
Programmed operation mode
speed 3
0.00Hz
0～650.00Hz
---
04-22
P.134
Programmed operation mode
speed 4
0.00Hz
0～650.00Hz
---
04-23
P.135
Programmed operation mode
speed 5
0.00Hz
0～650.00Hz
---
04-24
P.136
Programmed operation mode
speed 6
0.00Hz
0～650.00Hz
---
04-25
P.137
Programmed operation mode
speed 7
0.00Hz
0～650.00Hz
---
04-26
P.138
Programmed operation mode
speed 8
0.00Hz
0～650.00Hz
---
04-27
P.101
Programmed operation mode
speed 1 operating time
0.0s
0～6000.0s
---
04-28
P.102
Programmed operation mode
speed 2 operating time
0.0s
0～6000.0s
---
04-29
P.103
Programmed operation mode
speed 3 operating time
0.0s
0～6000.0s
---
04-30
P.104
Programmed operation mode
speed 4 operating time
0.0s
0～6000.0s
---
04-31
P.105
Programmed operation mode
speed 5 operating time
0.0s
0～6000.0s
---
04-32
P.106
Programmed operation mode
speed 6 operating time
0.0s
0～6000.0s
---
