Protection parameter group 06
PARAMETER DESCRIPTION 108
5.7 Protection parameter group 06
Group
Parameter
Number
Name
Setting Range
Default
Page
06-00
P.9
Electronic thermal relay capacity
0~500.00A
0.00A
110
06-01
P.22
Stall prevention operation level
0250.0%
150.0%
111
06-02
P.23
Stall prevention operation level
correction factor
0200.0%
99999
111
99999: Stall prevention operation level is the
setting value of 06-01(P.22).
06-03
P.66
Stall prevention operation
reduction starting frequency
50Hz system:0650.00Hz
50.00Hz
111
60Hz system:0650.00Hz
60.00Hz
06-05
P.30
Regenerative brake selection
0: Brake duty is fixed at 3%, parameter
06-06(P.70) will be off.
0
112
1: Brake duty is 06-06(P.70) value.
06-06
P.70
Special regenerative brake duty
0100.0%
0.0%
112
06-08
P.155
Over torque detection level
0200.0%
0.0%
113
06-09
P.156
Over torque detection time
060.0s
1.0s
113
06-10
P.260
Action when detect over torque
0: OL2 alarm will not be reported after over
torque detection, and inverter keeps running.
1
113
1: OL2 alarm will be reported after over
torque detection, and inverter stops.
06-12
P.245
Cooling fan working mode
0When running turn on the fan, after stop for
30 seconds turn off the fan.
1
114
1When power on turn on the fan, after
power off turn off the fan.
2When running and the heat sink
temperature exceeds 60 turn on the fan,
under 40 turn off the fan.
3When the heat sink temperature exceeds
60 turn on the fan, under 40 turn off the
fan.
06-13
P.281
Input phase loss protection
0: Off
0
114
1: When input phase loss, built-in keypad
shows IPF alarm and inverter stops
06-17
P.261
Maintenance alarm function
0: Off
0
114
19998day: Used to set the time for
maintenance alarm output signal
06-18
P.280
Detection for leakage current of
ground when starting
XX0Off
0
114
XX1Detect leakage current of ground when
inverter starts
0X1Detect leakage current of ground only
for the first startup
1X1Detect leakage current of ground for
every startup.
06-19
P.282
GF detection level when operating
0100%
50%
114
