Shihlin electric SC3 Series User Manual

Communication parameter group 07
PARAMETER DESCRIPTION 119
5.8 Communication parameter group 07
Group
Parameter
number
Name
Setting range
Default
Page
07-00
P.33
Communication protocol
selection
0：Modbus protocol
1
120
1：Shihlin protocol
07-01
P.36
Inverter communication
station number
0～254
0
120
07-02
P.32
Serial communication baud
rate
0：baud rate :4800bps
1
120
1：baud rate :9600bps
2：baud rate :19200bps
3：baud rate :38400bps
4：baud rate :57600bps
5：baud rate :115200bps
07-03
P.48
Data length
0：8bit
0
120
1：7bit
07-04
P.49
Stop bit length
0：1bit
0
120
1：2bit
07-05
P.50
Parity check selection
0：No parity check
0
120
1：Odd
2：Even
07-06
P.51
CR/LF selection
1: CR only
1
120
2：Both CR and LF
07-07
P.154
Modbus communication
format
0：1、7、N、2 (Modbus, ASCII)
4
120
1：1、7、E、1 (Modbus, ASCII)
2：1、7、O、1 (Modbus, ASCII)
3：1、8、N、2 (Modbus, RTU)
4：1、8、E、1 (Modbus, RTU)
5：1、8、O、1 (Modbus, RTU)
6：1、8、N、1 (Modbus, RTU)
07-08
P.52
Number of communication
retries
0～1000
5
120
07-09
P.53
Communication interval
allowed time
0～999.8s：Check communication timeout with the
set value
99999
120
99999：No timeout check
07-10
P.153
Communication alarm action
0：Alarm and stop freely
0
120
1：No alarm and continuing to operation
07-11
P.34
Communication EEPROM
write-in selection
0：When writing parameters through
communication, write in RAM and EEPROM
0
135
1：When writing parameters through
communication, only write into RAM
