Digital input/ output parameter group 03
PARAMETER DESCRIPTION 89
5.4.1 Digital input terminals function selection
 Use the following parameters to change the digital input terminal functions. Each terminal may choose any
function between 0～45 (Note 1)
Parameter
Name
Default
Setting Range
Content
03-00
P.83
Terminal STF
input function
0
0
STF(Inverter runs forward)
1
STR(Inverter runs reverse)
2
RL(Multi-speed low speed)
3
RM(Multi-speed medium speed)
4
RH(Multi-speed high speed)
5
Reserved
6
OH(External thermal relay actuate)
7
MRS(Stops inverter output immediately)
8
RT(Inverter second function)
9
EXJ(External JOG)
10
STF+EXJ
11
STR+EXJ
12
STF+RT
13
STR+RT
14
STF+RL
15
STR+RL
16
STF+RM
17
STR+RM
18
STF+RH
19
STR+RH
20
STF+RL+RM
21
STR+RL+RM
22
STF+RT+RL
23
STR+RT+RL
24
STF+RT+RM
25
STR+RT+RM
26
STF+RT+RL+RM
27
STR+RT+RL+RM
28
RUN(Inverter runs forward)
29
STF/STR(use with RUN signal, when ON, motor runs
reverse； when OFF, motor runs forward)
30
RES(External reset function)
31
STOP(Use as three line control with RUN signal and
STF-STR signal)
32
REX(Extend multi-speed to 16 levels)
33
PO(In “external mode", run programmed operation)
34
RES_E (External reset, valid only when alarm.)
35
MPO (In “external mode” run manual cycle operation.)
36
TRI(Triangle wave function)
37~38
Reserved
