Shihlin electric SC3 Series User Manual

Electric specification
INVERTER INTRODUCTION 14
3.1.3 220V series single phase
Frame
A
B
Model SC3-021-□□□K-xy
0.2
0.4
0.75
1.5
2.2
Inverter
Output
Rated output capacity (kVA)
0.6
1
1.5
2.5
4.2
Rated output current (A)
1.8
2.7
4.5
8
11
Applicable motor capacity (HP)
0.25
0.5
1
2
3
Applicable motor capacity (kW)
0.2
0.4
0.75
1.5
2.2
Overload current rating
150% 60 seconds, 200% 1 seconds (inverse-time characteristics)
Carrier frequency (kHz)
1~15kHz
Maximum output voltage
3 phase 200-240V
Power
Supply
Rated input current (A) *Note 1
single phase 200-240V 50Hz / 60Hz
Rated input AC voltage/
frequency
single phase 170-264V 50Hz / 60Hz
Permissible AC voltage
fluctuation
±5%
Permissible frequency
fluctuation
0.75
1.5
2.5
3.5
6.4
Power supply capacity (kVA)
5.4
6.5
9.3
15.7
24
Cooling method
No fan
Fan cooling
Weight (kg)
0.66
0.68
0.73
1.38
1.4
Note 1: The value indicates the current at rated output. The rated input current value is not only affected by power
transformer, input side reactor, wiring condition, but also fluctuates with the impedance of the power supply side.

Shihlin electric SC3 Series Specifications

General

Brand	Shihlin electric
Model	SC3 Series
Category	Inverter
Language	English
