Shihlin electric SC3 Series User Manual

Appendix 5 Optional equipment
Appendix 205
7.5.2 DU06 Keypad
 DU06 appearance
Order number:
NO.
Model
Name
Order code
1
DU06
DU06 keypad
SNKDU06
 DU06 dimention：
 DU06 Recommended screw installation size：
19.3
52.4
19.8
26.2
33.7
5.1
<Screw installation:panel cutting dimension drawing>
Cutout
Area
 DU06 Snap-in installation hole size：
38.7
69
<Snap-fit installation: panel cutting dimension drawing>
68.6
38.7
Cutout Area Cutout Area
Suitable for 2mm
panel thickness
Suitable for 1.2mm
panel thickness
72.0000
42.4000
8.1
8.3
Effective depth of screws hole 2.9mm
2×M3
26.2
52.4
38.65
9.45 15.8
42.4
72
<Outline drawing>
