Appearance and dimensions
INVERTER INTRODUCTION 17
3.3.2 Frame B/C/D
unit：mm
Model
W
W1
H
H1
H2
D
S1
SC3-021-1.5K
136
125
147
136
26.5
128
5
(tighten torque
20~25kgf.cm)
SC3-021-2.2K
SC3-023-2.2K
SC3-023-3.7K
SC3-043-2.2K
SC3-043-3.7K
SC3-043-5.5K
SC3-043-7.5K/11KF
132
115.6
215
198.6
Note 1
150
6.2
(tighten torque
20~25kgf.cm)
SC3-043-11K/15KF
SC3-043-15K/18.5KF
175
158.6
260
243.6
Note 1
180
6.2
(tighten torque
20~25kgf.cm)
SC3-043-18.5K/22KF
SC3-043-22K
Note1: Frame C and frame D do not have this feature, that is, they do not support DIN rail installation
H1 H
S1
W1
W
D
H2
