Shihlin electric SC3 Series User Manual

Motor parameter group 05
PARAMETER DESCRIPTION 107
5.6.2 Motor parameter
 Inverter has built-in standard parameters for motor. Modify the default values according to the actual situation to
conform to the actual values as much as possible.
Parameter
Name
Default
Setting Range
Content
05-01
P.302
Motor rated power
0.00kW
0～160.00kW
---
05-02
P.303
Motor poles
4
0～256
---
05-03
P.304
Motor rated voltage
380V/440V
0～510V
440V 50Hz/60Hz system
220V
220V system
05-04
P.305
Motor rated
frequency
50.00Hz
0～650.00Hz
50Hz system (when 00-24(P.189)=1)
60.00Hz
60Hz system (when 00-24(P.189)=0)
05-05
P.306
Motor rated current
According
to kw
0～500.00A
05-06
P.307
Motor rated rotation
speed
1410r/min
0～65000r/min
50Hz system (when 00-24(P.189)=1)
1710r/min
60Hz system (when 00-24(P.189)=0)
05-07
P.308
IM Motor excitation
current
According
to kw
0～500.00A
05-08
P.309
IM motor stator
resistance
According
to kw
0～99.98Ω
Motor parameter
 If induction motor can be completely disconnected from the load, select 05-00(P.301)=1 run motor to measure,
then press or on keypad and inverter will automatically calculate following parameters:
05-07(P.308)~05-08(P.309)
 If induction motor cannot be completely separated from the load, select 05-00(P.301)=2 don’t run motor to
measure, then press or on keypad and inverter will automatically calculate following
parameters:05-07(P.308)~05-08(P.309)

Users can also calculate these two parameters according to motor nameplate, parameters motor nameplate used
are: rated voltage U, rated current
I
, rated frequency
f
and power factor

.

Calculation method of no-load excitation current and mutual inductance of the motor is as follows, where

L
is
leakage inductance of the motor.

Idling current:
2
0
1   II
, Mutual inductance calculation:


L
If
U
L
m



0
32
,
0
I
is the idling current,，
m
L
is mutual inductance,

L
is leakage inductance.
Note: 1. When inverter is used with different size motor, please be sure to set parameters
05-01(P.302)~05-06(P.307)。Vector control relies heavily on motor parameters, so to obtain good control
performance, accurate parameters of the motor controlled must be set.
2. If one or more parameter values in 05-01(P.302)~05-08(P.309) have been manually modified, reset the
inverter to reload the new parameter values.
Setting
