Replacement procedure of fan
INVERTER INTRODUCTION 34
3.8 Replacement procedure of fan
3.8.1 Frame A/B
1. Press the hooks on both sides of the fan cover to
remove the fan cover, as shown in the figure below.
2. After disconnecting the fan connector, take out the fan,
as shown in the figure below.
3.8.2 Frame C/D
1. Press the hooks on both sides of the fan cover to
remove the fan cover, as shown in the figure below.
2. After disconnecting the fan connector, take out the fan,
as shown in the figure below.
