Shihlin electric SC3 Series User Manual

Protection parameter group 06
PARAMETER DESCRIPTION 114
5.7.5 Cooling fan working mode
 Control the start and stop conditions of the fan and the alarm output mode through parameter settings.
Parameter
Name
Default
Setting Range
Content
06-12
P.245
Cooling fan working
mode
1
0
When running turn on the fan, after stop for 30 seconds
turn off the fan.
1
When power on turn on the fan, after power off turn off the
fan.
2
When running and the heat sink temperature exceeds
60℃ turn on the fan, under 40℃ turn off the fan.
3
When the heat sink temperature exceeds 60℃ turn on
the fan, under 40℃ turn off the fan.
Note: According to the environmental conditions of the inverter installation, if the fan can be set reasonably to run as
little as possible, the life of the fan can be extended.
5.7.6 Maintenance alarm function
 Inverter counts operation time and trigger maintenance alarm output signal after time set.
Parameter
Name
Default
Setting Range
Content
06-17
P.261
Maintenance alarm
function
0
0
Off
1～9998day
Used to set the time for maintenance alarm output signal
Maintenance alarm function

When the multi-function digital output terminal function selection (03-11 (P.85)) is equal to 18, it is the maintenance
alarm function. That is, when the number of operating days of the inverter reaches the setting value of the
maintenance alarm function 06-17 (P.261) value, the inverter multi-function relay will output a signal.
5.7.7 Short circuit to ground protection
 Use parameters to control whether to enable ground leakage current detection, and set the detection level.
Parameter
Name
Default
Setting Range
Content
06-18
P.280
Short circuit to ground
protection function
when start
0
XX0
Off
XX1
Detect leakage current of ground when inverter starts
0X1
Detect leakage current of ground only for the first startup
1X1
Detect leakage current of ground for every startup
06-19
P.282
GF detection level
when operating
50%
0～100%
---
Short circuit to ground protection
 The short circuit to ground detection when start is only implemented after the start signal is input to the inverter.
 06-18 (P.280) is used to set short circuit to ground protection function when start or not, the ground leakage
current detection during operation is set by 06-19 (P.282)
 If short circuit to ground detection when start is selected, and the output short-circuit current to ground is detected,
and the percentage of the short-circuit current corresponding to the rated current exceeds 06-19 (P.282), the
inverter stops output and alarm GF.
Setting
Setting
