7.5.5 PU302 Keypad
42.7
18.0
7.6
26.3
42.7
18.0
7.6
26.3
 Order number:
NO.
Model
Name
Order code
1
PU302
LED keypad
SNKPU302
 Outline
74
42.7
27.9
18.0
7.6
52.6
26.3
8.2
9.2
2-M3
 Recommended screw installation size
open
hole
<螺丝安装面板开孔尺寸图>
19.3
52.4
19.8
26.2
33.7
5.1
 Recommended installation size
open
hole
open
hole
<卡扣安装面板开孔尺寸图>
38.7
68.6
38.7
69
This steel plate
thickness is 2mm
This steel plate
thickness is 1.2mm
