Protection parameter group 06
PARAMETER DESCRIPTION 117
5.7.11 Fire mode
 Fire mode applies to the field of fire control
Fire mode
 Start fire mode
When 06-84（P.207）=XXX1 or XXX2 and multi-function terminal=92 is ON, the inverter goes into fire mode: the
inverter frequency accelerates to 06-85（P.208）set up value, fire warning shows on the keypad panel, and the inverter
mode is in fire mode. The accumulated times of inverter in fire mode records in 06-88（P.209）. If multi-function output
terminal=42, the inverter provides the fire mode operating command output.
 An alarm happens in fire mode
When in fire mode, if an alarm happens, the inverter starts to reset after wait for 10-14(P.68) seconds. There is no
upper limit times to reset the inverter. Any alarm happens, the inverter stops immediately and motor runs in idle speed.
When reset starts, if over-current alarm happens, the inverter can use parameter 10-08(P.150)= 32 to avoid.
 Exit fire mode
When input terminal=92/93 , the terminal is ON and then OFF
1.06-84(P.207)= 0XXX means manually exit fire mode 1 : stop the inverter, power OFF, and then power ON/reset the
inverter to exit.
2.06-84(P.207)= 1XXX means exit fire mode automatically: the inverter stops and return to normal mode automatically.
3. 06-84(P.207)= 2XXX means manually exit fire mode 2: the inverter keeps running, power OFF and then power
ON/reset to exit.
Note：
1.When in fire mode, the running direction of the inverter is base on 06-84(P.207)=XXX1(forward)orXXX2(reverse).
The other running direction are all disabled. Parameter 00-15（P.78）forward &reverse running are disabled as well.
2.When in fire mode, all keypad command are ignored.(Including RUN,STOP and JOG commands).
3.When in fire mode, all RS-485 communication commands are ignored.(Including RUN, STOP and JOG commands)
4.When in fire mode, the JOG command is invalid.(JOG command source: keypad, external terminals and
communications.) Any operating JOG command is invalid automatically.
Parameter
Name
Default Value
Setting Range
Content
06-84
P.207
Fire Mode
0
XXX0
Invalid：Fire mode is forbidden( normal mode)
XXX1
Forward operation：The inverter runs forward in fire mode
XXX2
Reverse operation：The inverter runs reversely in fire mode
0XXX
Manually exit fire mode 1：If the start fire mode terminal is
OFF, the inverter need reset manually and back to normal
mode
1XXX
Exit fire mode automatically：If the start fire mode terminal is
OFF, the inverter goes to normal mode automatically
2XXX
Manually exit fire mode 2：If the start fire mode terminal is
OFF, the inverter keeps running, need reset manually and
back to normal mode
06-85
P.208
Frequency
setting in fire
mode
60.00Hz
0~650.00Hz
Fire mode target frequency
06-88
P.209
Accumulated
times in fire
mode
0
Read only
Number of times in fire mode
Setting
