Multi-speed parameter group 04
PARAMETER DESCRIPTION 100
5.5.1 16 steps speed
 With the combination of digital input terminal RL, RM, RH and REX, 16 steps speed can be selected (up to 16
speeds)
Parameter
Name
Default
Setting Range
Content
04-00
P.4
Speed 1 (high speed)
60.00Hz
0～650.00Hz
---
04-01
P.5
Speed 2 (medium
speed)
30.00Hz
0～650.00Hz
---
04-02
P.6
Speed 3 (low speed)
10.00Hz
0～650.00Hz
---
04-03
P.24
Speed 4
99999
0～650.00Hz
---
99999
99999: Off
04-04
P.25
Speed 5
99999
Same as 04-03
Same as 04-03
04-05
P.26
Speed 6
99999
Same as 04-03
Same as 04-03
04-06
P.27
Speed 7
99999
Same as 04-03
Same as 04-03
04-07
P.142
Speed 8
0.00Hz
Same as 04-03
Same as 04-03
04-08
P.143
Speed 9
99999
Same as 04-03
Same as 04-03
04-09
P.144
Speed 10
99999
Same as 04-03
Same as 04-03
04-10
P.145
Speed 11
99999
Same as 04-03
Same as 04-03
04-11
P.146
Speed 12
99999
Same as 04-03
Same as 04-03
04-12
P.147
Speed 13
99999
Same as 04-03
Same as 04-03
04-13
P.148
Speed 14
99999
Same as 04-03
Same as 04-03
04-14
P.149
Speed 15
99999
Same as 04-03
Same as 04-03
16 steps speed

If all the values of 04-03~04-06(P.24~P.27), 04-08~04-14(P.143~P.149) are not 99999, “16 steps speed” is active.
It means with the combination of RL, RM, RH and REX, there are 16 speeds in total. To set target frequency for
inverter, please refer to the figure below:
