Basic Parameter Group 01
PARAMETER DESCRIPTION 74
5.2.10 Second function
When given RT signal, these parameters will work.
01-08(P.21)=0 / 01-08(P.21)=1
01-08(P.21)=0 / 01-08(P.21)=1
Second function
When 01-08(P.21)=0, minimum acceleration / deceleration time 01-22(P.44), 01-23(P.45) increment is 0.01s.
When 01-08(P.21)=1, minimum acceleration / deceleration time 01-22(P.44), 01-23(P.45) increment is 0.1s.
When RT is “on”, second function is valid. For the motor operation characteristics, please refer to the following
second function setting.
If 01-22(P.44)≠99999 and 01-23(P.45)=99999, when RT is “on”, acceleration /deceleration time is the “set value
of 01-22(P.44)”.
If 01-22(P.44)≠99999 and 01-24(P.46)=99999, when RT is “on”, torque boost is the “set value of 01-10(P.0)”.
If 01-22(P.44)≠99999 and 01-24(P.46)≠99999, when RT is “on”, torque boost is the “set value of 01-24(P.46)”.
If 01-22(P.44)≠99999 and 01-25(P.47)=99999, when RT is “on”, base frequency is the “set value of 01-03(P.3)”.
If 01-22(P.44)≠99999 and 01-25(P.47)≠99999, when RT is “on”, base frequency is the “set value of 01-25(P.47)”.
Note: RT mentioned here is the function name of “multi-function digital input terminal”. Please refer to 03-00(P.83),
03-01(P.84), 03-03(P.80), 03-04(P.81) for function selection of multi-function digital input terminal; please refer
to Section 3.7 Terminal wire arrangement.
